CPU|INTEL|Desktop|Core i3|i3-14100F|Raptor Lake|3500 MHz|Cores 4|12MB|Socket LGA1700|58 Watts|BOX|BX8071514100FSRMX2

Datu lapa

SUMMARY

INTEL CORE I3-14100F. PROCESSOR FAMILY: INTEL® CORE™ I3, PROCESSOR SOCKET: LGA 1700, PACKAGE TYPE: BOX. MEMORY CHANNELS: DUAL-CHANNEL, MAXIMUM INTERNAL MEMORY SUPPORTED BY PROCESSOR:

CATEGORY CODE

CPU

CNCODE

85423190

PROCESSOR BOOST FREQUENCY, GHz

4.7

PROCESSOR CACHE TYPE

SMART CACHE

PROCESSOR CORES

4

Processor family

INTEL® CORE™ I3

Processor manufacturer

Intel

Processor model

I3-14100F

PROCESSOR GENERATION

INTEL® CORE™ I3 (14TH GEN)

PROCESSOR THREADS

8

MAXIMUM INTERNAL MEMORY, GB

192

MEMORY CHANNELS

DUAL-CHANNEL

DISCRETE GRAPHICS CARD

NO

DISCRETE GRAPHICS CARD MODEL

NOT AVAILABLE

ON-BOARD GRAPHICS CARD

NO

ON-BOARD GRAPHICS CARD MODEL

NOT AVAILABLE

PERFORMANCE CORES

4

UNITS PER SHIPPING BOX

5

UNIT CALCULATED VOLUME, cubm

0.001264

UNIT CALCULATED WEIGHT, kg

0.492

MAXIMUM TURBO POWER, W

110

PROCESSOR BASE POWER, W

58

PROCESSOR CACHE, MB

12

UNIT BOX HEIGHT

0.08

UNIT BOX LENGTH

0.125

UNIT BOX WIDTH

0.11

COOLER INCLUDED

YES

HARMONIZED SYSTEM (HS) CODE

8542310001

MAXIMUM NUMBER OF DMI LANES

8

PACKAGE TYPE

Box

PERFORMANCE-CORE BASE FREQUENCY, GHz

3.5

PERFORMANCE-CORE BOOST FREQUENCY, GHz

4.7

MEMORY BANDWIDTH SUPPORTED BY PROCESSOR (MAX), GB/s

76.8

PROCESSOR ARK ID

236786

PROCESSOR OPERATING MODES

64-BIT

PROCESSOR SOCKET

LGA 1700

PROCESSOR CODENAME

RAPTOR LAKE

MAXIMUM INTERNAL MEMORY SUPPORTED BY PROCESSOR, GB

192

MEMORY BANDWIDTH (MAX), GB/s

76.8

MEMORY TYPES SUPPORTED BY PROCESSOR

DDR4-SDRAM/DDR5-SDRAM

STEPPING

H0

CPU CONFIGURATION (MAX)

1

DIRECT MEDIA INTERFACE (DMI) REVISION

4.0

EMBEDDED OPTIONS AVAILABLE

NO

EXECUTE DISABLE BIT

YES

EXPORT CONTROL CLASSIFICATION NUMBER (ECCN)

5A992C

IDLE STATES

YES

MARKET SEGMENT

DESKTOP

MAXIMUM NUMBER OF PCI EXPRESS LANES

20

PCI EXPRESS CONFIGURATIONS

1X16+1X4/2X8+1X4

PCI EXPRESS SLOTS VERSION

4.0/5.0

SCALABILITY

1S

SUPPORTED INSTRUCTION SETS

AVX 2.0/SSE4.1/SSE4.2

THERMAL MONITORING TECHNOLOGIES

YES

USE CONDITIONS

PC/CLIENT/TABLET

ENHANCED INTEL SPEEDSTEP TECHNOLOGY

YES

INTEL 64

YES

INTEL VIRTUALIZATION TECHNOLOGY (VT-X)

YES

INTEL VIRTUALIZATION TECHNOLOGY FOR DIRECTED I/O (VT-D)

YES

INTEL VT-X WITH EXTENDED PAGE TABLES (EPT)

YES

INTEL® AES NEW INSTRUCTIONS (INTEL® AES-NI)

YES

INTEL® BOOT GUARD

YES

INTEL® CONTROL-FLOW ENFORCEMENT TECHNOLOGY (CET)

YES

COMMODITY CLASSIFICATION AUTOMATED TRACKING SYSTEM (CCATS)

740.17B1

INTEL® DEEP LEARNING BOOST (INTEL® DL BOOST) ON CPU

YES

INTEL® HYPER THREADING TECHNOLOGY (INTEL® HT TECHNOLOGY)

YES

INTEL® OS GUARD

YES

INTEL® SECURE KEY

YES

INTEL® SPEED SHIFT TECHNOLOGY

YES

INTEL® STANDARD MANAGEABILITY (ISM)

YES

INTEL® TURBO BOOST TECHNOLOGY

2.0

INTEL® VOLUME MANAGEMENT DEVICE (VMD)

YES

MODE-BASED EXECUTE CONTROL (MBE)

YES

TJUNCTION, °C

100

LAUNCH DATE

Q1'24

STATUS

LAUNCHED

PROCESSOR PACKAGE SIZE, mm

45 X 37.5

L2 CACHE, KB

5120

CPU FAMILY NAME

INTEL CORE I3

MODEL NUMBER

I3-14100F

INTEL® GAUSSIAN & NEURAL ACCELERATOR (INTEL® GNA) 3.0

YES
