CPU|INTEL|Desktop|Intel Core i7|i7-14700F|Raptor Lake|2100 MHz|Cores 20|33MB|Socket LGA1700|65 Watts|BOX|BX8071514700FSRN3Z

Datu lapa

SUMMARY

INTEL CORE I7-14700F. PROCESSOR FAMILY: INTEL® CORE™ I7, PROCESSOR SOCKET: LGA 1700, PACKAGE TYPE: BOX. MEMORY CHANNELS: DUAL-CHANNEL, MAXIMUM INTERNAL MEMORY SUPPORTED BY PROCESSOR:

CATEGORY CODE

CPU

CNCODE

85423190

UNIT BOX HEIGHT

0.12

UNIT BOX LENGTH

0.11

COOLER INCLUDED

YES

UNIT BOX WIDTH

0.08

EFFICIENT CORES

12

EFFICIENT-CORE BASE FREQUENCY, GHz

1.5

EFFICIENT-CORE BOOST FREQUENCY, GHz

4.2

MAXIMUM TURBO POWER, W

219

MAXIMUM NUMBER OF DMI LANES

8

PACKAGE TYPE

Box

PERFORMANCE CORES

8

PERFORMANCE-CORE BASE FREQUENCY, GHz

2.1

PERFORMANCE-CORE BOOST FREQUENCY, GHz

5.3

MEMORY BANDWIDTH SUPPORTED BY PROCESSOR (MAX), GB/s

89.6

PROCESSOR BASE POWER, W

65

PROCESSOR BOOST FREQUENCY, GHz

5.4

PROCESSOR CACHE, MB

33

PROCESSOR CACHE TYPE

SMART CACHE

PROCESSOR ARK ID

236854

PROCESSOR CORES

20

Processor family

INTEL® CORE™ I7

PROCESSOR GENERATION

INTEL® CORE™ I7 (14TH GEN)

Processor manufacturer

Intel

Processor model

I7-14700F

PROCESSOR OPERATING MODES

64-BIT

PROCESSOR SOCKET

LGA 1700

PROCESSOR THREADS

28

PROCESSOR CODENAME

RAPTOR LAKE

MAXIMUM INTERNAL MEMORY SUPPORTED BY PROCESSOR, GB

192

MEMORY BANDWIDTH (MAX), GB/s

89.6

MEMORY CHANNELS

DUAL-CHANNEL

MEMORY TYPES SUPPORTED BY PROCESSOR

DDR4-SDRAM/DDR5-SDRAM

DISCRETE GRAPHICS CARD

NO

DISCRETE GRAPHICS CARD MODEL

NOT AVAILABLE

ON-BOARD GRAPHICS CARD

NO

ON-BOARD GRAPHICS CARD MODEL

NOT AVAILABLE

STEPPING

B0

CPU CONFIGURATION (MAX)

1

DIRECT MEDIA INTERFACE (DMI) REVISION

4.0

EMBEDDED OPTIONS AVAILABLE

NO

EXECUTE DISABLE BIT

YES

EXPORT CONTROL CLASSIFICATION NUMBER (ECCN)

5A992C

IDLE STATES

YES

MARKET SEGMENT

DESKTOP

MAXIMUM NUMBER OF PCI EXPRESS LANES

20

PCI EXPRESS CONFIGURATIONS

1X16+1X4/2X8+1X4

PCI EXPRESS SLOTS VERSION

4.0/5.0

SCALABILITY

1S

SUPPORTED INSTRUCTION SETS

AVX 2.0/SSE4.1/SSE4.2

THERMAL MONITORING TECHNOLOGIES

YES

USE CONDITIONS

PC/CLIENT/TABLET

ENHANCED INTEL SPEEDSTEP TECHNOLOGY

YES

INTEL 64

YES

INTEL TURBO BOOST MAX TECHNOLOGY 3.0

YES

INTEL VIRTUALIZATION TECHNOLOGY (VT-X)

YES

INTEL VIRTUALIZATION TECHNOLOGY FOR DIRECTED I/O (VT-D)

YES

INTEL VT-X WITH EXTENDED PAGE TABLES (EPT)

YES

INTEL® AES NEW INSTRUCTIONS (INTEL® AES-NI)

YES

INTEL® BOOT GUARD

YES

INTEL® CONTROL-FLOW ENFORCEMENT TECHNOLOGY (CET)

YES

COMMODITY CLASSIFICATION AUTOMATED TRACKING SYSTEM (CCATS)

740.17B1

INTEL® DEEP LEARNING BOOST (INTEL® DL BOOST) ON CPU

YES

INTEL® HYPER THREADING TECHNOLOGY (INTEL® HT TECHNOLOGY)

YES

INTEL® OS GUARD

YES

INTEL® SECURE KEY

YES

INTEL® SPEED SHIFT TECHNOLOGY

YES

INTEL® STANDARD MANAGEABILITY (ISM)

YES

INTEL® THREAD DIRECTOR

YES

INTEL® TURBO BOOST MAX TECHNOLOGY 3.0 FREQUENCY, GHz

5.4

INTEL® TURBO BOOST TECHNOLOGY

2.0

INTEL® VOLUME MANAGEMENT DEVICE (VMD)

YES

MODE-BASED EXECUTE CONTROL (MBE)

YES

TJUNCTION, °C

100

HARMONIZED SYSTEM (HS) CODE

8542310001

LAUNCH DATE

Q1'24

STATUS

LAUNCHED

PROCESSOR PACKAGE SIZE, mm

45 X 37.5

L2 CACHE, KB

28672

MAXIMUM INTERNAL MEMORY, GB

192

CPU FAMILY NAME

INTEL CORE I7

MODEL NUMBER

I7-14700F

UNITS PER SHIPPING BOX

5

UNIT CALCULATED VOLUME, cubm

0.001279

UNIT CALCULATED WEIGHT, kg

0.507

INTEL® GAUSSIAN & NEURAL ACCELERATOR (INTEL® GNA) 3.0

YES

Model

INTEL CORE I7 14700F (BX8071514700F S RN3Z)
